Sherwin-Williams Firetex FX5060

FX5060/20
£354.00 inc. tax

£295.00 ex. tax
? Tax based on United Kingdom.
Notify me when product is back in stock
Sherwin-Williams Firetex FX5060 Summary

Sherwin-Williams Firetex FX5060

This product is now discontinued. See Sherwin Williams Firetex FX5062 as a possible alternative.


Sherwin-Williams Firetex FX5060
Intumescent Coating For Structural Steelwork

  • Waterborne intumescent coating designed for internal structural steelwork
  • Provides 30 and 60 minutes resistance
  • This product has been tested and assessed in accordance with the ASFP fire testing protocol for cellular beam protection
  • Highly competitive loadings
  • Easy application properties
  • TCEP free thin film intumescent coating
  • Topseal is not required, however, where a finish colour has been specified we can supply a suitable topseal available in a wide range of BS4800 or RAL colours


Data Sheets


FX5060 Data Sheet

FX5060 Safety Data Sheet


Guidance Notes:

The thickness of an intumescent coating is dependent on the steel section used.  For calculation of DFT (dry film thickness) a factor called HP/A (heated perimeter divided by cross sectional area) is used.  Intumescent coatings are applied as an intermediate coat in a coating system (primer, intermediate and top/finish coat if required).  NB: HP/A is generally used with British testing and A/V in European testing, however, the principles are the same and both are accepted methods of calculating the steel section factor.

The rate increase in temperature of a steel cross-section is determined by the ratio of the heated surface area (A) to the Volume (V).  This ratio A/V, has units of m-1 and is known as the “Section Factor”.  Steel members with low Section Factors will heat up more slowly.  A steel section with a large surface area (A) will receive more heat than one with a smaller surface area.  Also, the greater the volume (V) of the section, the greater the heat sink.  Therefore, a small thick section will be slower to increase in temperature than a large thin one.  The Section Factor (A/V or HP/A) is thus a measure of the rate at which a section will heat up in a fire.  The higher the value of the Section Factor the greater the protection thickness required.

Steel Preparation & Primers:

A primer is used as a preparatory coating put on the steel before applying the intumescent paint and acts to provide corrosion protection.  Priming ensures better adhesion of the intumecent paint to the surface, increases its durability, and provides additional protection for the material being painted and is always recommended.

A primer designed for steel is still highly recommended if a part is to be exposed to moisture.  Once water seeps through to the bare metal, oxidation will begin (plain steel will simply rust). Metal primers might contain additional materials to protect against corrosion, such as sacrificial zinc.

Metal hydroxides/oxides do not provide a solid surface for the paint to adhere to and paint will come off in large flakes. Using a primer will provide extra insurance against such a scenario. An additional reason for using a primer on the steel could be the poor condition of the surface.  A steel part can be rusty, for example and should be prepared to the Swedish Standard 2.5 in accordance with BS7079 Part A1.

FX5060 should be applied to clean, dry and primed steels.  Extensive primer compatibility tests have been undertaken on single and two pack products commercially available.  Bituminous and chlorinated rubber primers are unsuitable because of their poor performance in fire conditions.  Zinc rich primers require a tie coat before application of FX5060. If you are ever unsure of the primer and its compatibility then please send us the details of the primer and we will confirm compatibility.  Must not be applied directly to galvanised steel and zinc rich primers.

Recommended Topcoats

If it can be guaranteed that application and subsequent in-service conditions will be in a C1 environment as defined in ISO 12944-2:1998, then no topcoat is required.

Envirogard M770 is the reccomended topcoat and should be used for any subsequent re-decoration.

Firetex M71V2, Resistex C137V2 or Resistex C237 may be used in place of Envirogard M770 if circumstances require it.  Either coating should be applied within 7 days for best performance.

Can we help?

If you would like to send us your steel sizes we would be happy to calculate the loadings required using FX5060.  We would recommend that intumescent coatings are carried out by an approved applicator.

All orders are usually despatched within 24 hours of receiving cleared payment (Mon–Fri).

The above information is based on current test data, health and safety information and application instructions supplied by our suppliers and manufacturers of the products. It is supplied for guidance and to the best of our knowledge is true and accurate. Customers should satisfy themselves to the suitability of the products in its intended use and no guarantee is given or implied as the conditions of actual use are beyond our control. If in doubt the customer should consult the designer of the project or the local building control.

Fire Stopping Shop, disclaim any liability for loss, damage or other expense which may arise from the use of this information, data or products refereed to and reserve the right to amend or change any details without notice. This statement does not affect your statuary rights.
