• Satin Stainless Steel
• Power size: 2 to 4 adjustable by spring tension
• Function: Closing speed, backcheck, latching
• Cover: Radiused cover
• Maximum door width: 1,100mm
• Maximum door weight: 80kg
• Arm application: Fig 1, Fig 6 and Fig 61 fixing positions
• Successfully type tested for conformity to all the requirements of BS EN 1154:1997 Door mount pull (Fig 1), door mount push (Fig 6), transom mount pull (Fig 61): 3 | 8 | 4/2 | 1* | 1 | 4
• Included in a successful fire test to BS EN 1634 Part 1. Assessed for use on 30, 60 and 120 minutes timber fire doors and 240 minutes on steel fire doors.
• CE Marked: AD0124
• Certifire approved: CF294; DOP: HUK0001
• The AR1500 can satisfy the opening force recommendations of BS 8300 and ADM when fitted in Fig 1 to a door with minimum width of 938mm according to third party data. However other installed hardware, door seals and differential air pressure will affect the products as fitted performance meaning that the door closer alone cannot allow compliance to BS 8300 and ADM.

Details

Cover finish: Satin Stainless Steel

Shape: Slimline

Power size: 2 to 4

Maximum door width: 1100mm

Maximum door weight: 80kg

Arm application: Figure 1, 6 and 61

Mechanism type: Rack & pinion

Door type: Wooden door

Fixings: Timber door

Arm finish: Satin Stainless Steel

Mechanism function: Backcheck, spring adjustment, closing/latching speed


Product Data Sheet Links

Model: AR1500
Item number: 87107182
Reference number: AR1500-SSS/SSS
