Carboline Phenoline 187 VOC 10L Kit
Carboline Phenoline 187 VOC 10L Kit
Phenoline 187 VOC High solids epoxy lining with exceptional chemical resistance. Primarily as a tank lining, it is recommended for storage of crude oil (180°F/82°C), demineralized water (150°F/65°C), tap water (200°F/93°C) food and beverage industries, and water and wastewater exposures. Is excellent as a protective coating under insulation, operating at (400°F/204°C). Outstanding resistance to wet/dry cycling conditions at these elevated temperatures.
Product Features
- High solids; Low VOC formula
- VOC compliant to current AIM regulations
- Excellent overall chemical resistance
- Excellent for crude-oil storage
- Excellent resistance up to 400°F(204°C)
- Excellent abrasion & thermal shock resistance
- Meets the FDA requirements for 21CFR 175.300 for direct food contact
- Passes EI 1541 jet fuel gum test
- Complies with MIL-PRF-4556F testing
| Color | Red (0500),Gray (0700); White (0800) |
| Finish | Semi-Gloss |
| Primer | Self-priming |
| Dry Film Thickness | 4 - 6 mils (102 - 152 microns) per coat Two coats are needed for optimum performance. A third coat may be applied for additional thickness and/or service life. |
| Solids Content | By Volume 84% +/- 2% |
| Theoretical Coverage Rate |
1347 ft²/gal at 1.0 mils (33.1 m²/l at 25 microns) 337 ft²/gal at 4.0 mils (8.3 m²/l at 100 microns) 225 ft²/gal at 6.0 mils (5.5 m²/l at 150 microns) Allow for loss in mixing and application. |
| VOC Value(s) | As Supplied : 1.00 lbs/gal (119 g/l) Thinner 2 : 20% by volume 2.00 lbs./gal (240 g/l) These are nominal values and may vary slightly with color. |
| Under Insulation Resistance |
Continuous: 400°F (204°C) Non-Continuous: 450°F (232°C) |
| Temperature Resistance (Immersion) |
Immersion temperature resistance depends upon exposure. Consult Carboline Technical Service for specific information. |
Data Sheets
Phenoline 187 VOC PDS
Phenoline 187 VOC (Hi Performance Catalyst) SDS Part B
Phenoline 187 VOC SDS Part A
Phenoline 187 VOC Product Flyer
