The Door & Hardware Federation (DHF) TS008: 2015 sets the advanced security requirements of letterplates. The updated door standard PAS 24:2016, now requires that a door fitted with a letterplate has to have a letterplate that is tested to and meets the requirements of TS008: 2015. As well as covering key fishing, TS008 also covers preventing being able to unlock the door through the letterplate, whilst also allowing postal items to pass freely through it.

Technical Specification

Application
Fire resisting, Secured by Design and/or PAS24
timber doorsets
Fixing
Bolted together
Performance
Smoke tested in accordance with BS EN 1634-3
Salt spray tested to BS EN 1670 - Class 5
20,000 cycles
Material
Aluminium (stainless steel Nanocoat option
available)
Door thickness (mm)
44 54 & 58
Size (mm)
Internal – 298×98
Colours
Black (BLK) / Gold Anodised (GA) / Satin Chrome (SC) / Satin Silver (SA) / White (WHT) / Chrome (C)
Door types
Composite (CIN) and Timber (TIN)
Fire rating
FD30 (30) and FD60 (60).
(FD60 only available for timber doors)

Data Sheets

Norseal Data Sheet

Certification CF 6025
